Ressourcenprofil: MII PR MolGen Mutationslast

Offizielle URL: https://www.medizininformatik-initiative.de/fhir/ext/modul-molgen/StructureDefinition/mutationslast Version: 2027.0.0-ballot.1
Active Stand: 2026-09-13 Maschinenlesbarer Name: MII_PR_MolGen_Mutationslast

Dieses Profil beschreibt die Gesamtzahl der in der DNA von Krebszellen gefundenen Mutationen.

Beschreibung

Dieses Profil beschreibt die Gesamtzahl der in der DNA von Krebszellen gefundenen Mutationen.

Das Profil ist abgeleitet vom Profil Tumor Mutation Burden aus HL7 Genomics Reporting Implementation Guide.

Profil

| FHIR-Element | Logischer Datensatz | |—|—| | Observation.valueQuantity | Ergebnisse.Mutationslast |

Examples

Beispiele

Von der Migration geschrieben, nicht aus der Quelle übernommen. Der Simplifier-Leitfaden hat diese Beispiele auf dieser Seite eingebettet; der IG Publisher rendert jedes auf einer eigenen Seite. Sie stehen deshalb hier als Links, in der Reihenfolge der Quelle und mit deren Bildunterschriften. Es wurde nichts ergänzt und nichts weggelassen.

Usages:

You can also check for usages in the FHIR IG Statistics

Formale Ansichten des Profilinhalts

Beschreibung von Profilen, Differentials, Snapshots und deren Repräsentationen.

NameFlagsCard.TypeDescription & Constraints    Filter: Filtersdoco
.. Observation C 0..* MII_PR_MolGen_MolekularerBiomarker Measurements and simple assertions
Constraints: obs-6, obs-7
... implicitRules ?!Σ 0..1 uri A set of rules under which this content was created
... modifierExtension ?! 0..* Extension Extensions that cannot be ignored
... status ?!SΣ 1..1 code Status
Binding: ObservationStatus (required): Codes providing the status of an observation.
.... category:labCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/observation-category
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: laboratory
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
.... category:mbCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
.... category:geCategory 0..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/v2-0074
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: GE
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
... code SΣ 1..1 CodeableConcept Code
Binding: Molecular Biomarker Codes (example)
... subject SΣ 1..1 Reference(Patient | Group) Patient
... encounter SΣ 0..1 Reference(Encounter) Kontakt
... effective[x] SΣ 0..1 Zeitpunkt der Beobachtung
.... effectiveDateTime dateTime
.... effectivePeriod Period
.... effectiveTiming Timing
.... effectiveInstant instant
... issued SΣ 0..1 instant Freigabedatum
... Slices for value[x] SΣC 0..1 Ergebniswert
Slice: Unordered, Open by type:$this
.... valueQuantity Quantity
.... valueCodeableConcept CodeableConcept
.... valueString string
.... valueBoolean boolean
.... valueInteger integer
.... valueRange Range
.... valueRatio Ratio
.... valueSampledData SampledData
.... valueTime time
.... valueDateTime dateTime
.... valuePeriod Period
.... value[x]:valueQuantity ΣC 0..1 Quantity Actual result
... specimen S 0..1 Reference(Specimen) Probe
... Slices for derivedFrom SΣ 0..* Reference(DocumentReference | ImagingStudy | Media | QuestionnaireResponse | Observation | MolecularSequence) Abgeleitet von
Slice: Unordered, Open by profile:resolve()
.... derivedFrom:variant Σ 0..* Reference(MII PR MolGen Variante) Variant the biomarker is derived from
.... derivedFrom:genotype Σ 0..* Reference(Genotype) Genotype the biomarker is derived from
.... derivedFrom:haplotype Σ 0..* Reference(Haplotype) Haplotype the biomarker is derived from
... Slices for component SΣ 0..* BackboneElement Komponenten
Slice: Unordered, Open by value:code
.... component:All Slices Content/Rules for all slices
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
.... component:gene-studied SΣ 0..* BackboneElement Untersuchtes Gen
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept 48018-6
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://loinc.org
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: 48018-6
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept The HGNC gene symbol is to be used as display text and the HGNC gene ID used as the code. If no HGNC code issued for this gene yet, NCBI gene IDs SHALL be used.
Binding: HUGO Gene Nomenclature Committee Gene Names (HGNC) (extensible)
.... component:biomarker-category SΣ 0..* BackboneElement Biomarker-Kategorie
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept cell receptor | antigen | protein | immune stain
Binding: Molecular Biomarker Categories (example)

doco Documentation for this format

Terminology Bindings

Path Status Usage ValueSet Version Source
Observation.status Base required ObservationStatus 📍4.0.1 FHIR Std.
Observation.category Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:labCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:mbCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:geCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.code Base example Molecular Biomarker Codes 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​value[x] Base extensible HUGO Gene Nomenclature Committee Gene Names (HGNC) 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component:biomarker-category.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​value[x] Base example Molecular Biomarker Categories 📦3.0.0 Genomics Reporting Implementation Guide v3.0

Constraints

Id Grade Path(s) Description Expression
dom-2 error Observation If the resource is contained in another resource, it SHALL NOT contain nested Resources contained.contained.empty()
dom-3 error Observation If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4 error Observation If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5 error Observation If a resource is contained in another resource, it SHALL NOT have a security label contained.meta.security.empty()
dom-6 best practice Observation A resource should have narrative for robust management text.`div`.exists()
ele-1 error **ALL** elements All FHIR elements must have a @value or children hasValue() or (children().count() > id.count())
ext-1 error **ALL** extensions Must have either extensions or value[x], not both extension.exists() != value.exists()
obs-6 error Observation dataAbsentReason SHALL only be present if Observation.value[x] is not present dataAbsentReason.empty() or value.empty()
obs-7 error Observation If Observation.code is the same as an Observation.component.code then the value element associated with the code SHALL NOT be present value.empty() or component.code.where(coding.intersect(%resource.code.coding).exists()).empty()

Diese Struktur ist abgeleitet von MII_PR_MolGen_MolekularerBiomarker

NameFlagsCard.TypeDescription & Constraints    Filter: Filtersdoco
.. Observation 0..* MII_PR_MolGen_MolekularerBiomarker Measurements and simple assertions
... status S 1..1 code Status
... code 1..1 CodeableConcept Code
... subject 1..1 Reference(Patient | Group) Patient
.... value[x]:valueQuantity 0..1 Quantity Actual result
... specimen S 0..1 Reference(Specimen) Probe

doco Documentation for this format
NameFlagsCard.TypeDescription & Constraints    Filter: Filtersdoco
.. Observation C 0..* MII_PR_MolGen_MolekularerBiomarker Measurements and simple assertions
Constraints: obs-6, obs-7
... id Σ 0..1 id Logical id of this artifact
... meta Σ 0..1 Meta Metadata about the resource
... implicitRules ?!Σ 0..1 uri A set of rules under which this content was created
... language 0..1 code Language of the resource content
Binding: CommonLanguages (preferred): A human language.
Additional BindingsPurpose
AllLanguages Max Binding
... text 0..1 Narrative Text summary of the resource, for human interpretation
This profile does not constrain the narrative in regard to content, language, or traceability to data elements
... contained 0..* Resource Contained, inline Resources
... extension 0..* Extension Additional content defined by implementations
... modifierExtension ?! 0..* Extension Extensions that cannot be ignored
... identifier Σ 0..* Identifier Business Identifier for observation
... basedOn Σ 0..* Reference(CarePlan | DeviceRequest | ImmunizationRecommendation | MedicationRequest | NutritionOrder | ServiceRequest) Fulfills plan, proposal or order
... partOf Σ 0..* Reference(MedicationAdministration | MedicationDispense | MedicationStatement | Procedure | Immunization | ImagingStudy) Part of referenced event
... status ?!SΣ 1..1 code Status
Binding: ObservationStatus (required): Codes providing the status of an observation.
... Slices for category S 2..* CodeableConcept Kategorie
Slice: Unordered, Open by value:coding
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
.... category:labCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
Slice: Unordered, Open by value:url
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/observation-category
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: laboratory
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
..... text Σ 0..1 string Plain text representation of the concept
.... category:mbCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
Slice: Unordered, Open by value:url
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
..... text Σ 0..1 string Plain text representation of the concept
.... category:geCategory 0..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
Slice: Unordered, Open by value:url
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/v2-0074
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: GE
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
..... text Σ 0..1 string Plain text representation of the concept
... code SΣ 1..1 CodeableConcept Code
Binding: Molecular Biomarker Codes (example)
... subject SΣ 1..1 Reference(Patient | Group) Patient
... focus Σ 0..* Reference(Resource) What the observation is about, when it is not about the subject of record
... encounter SΣ 0..1 Reference(Encounter) Kontakt
... effective[x] SΣ 0..1 Zeitpunkt der Beobachtung
.... effectiveDateTime dateTime
.... effectivePeriod Period
.... effectiveTiming Timing
.... effectiveInstant instant
... issued SΣ 0..1 instant Freigabedatum
... performer Σ 0..* Reference(Practitioner | PractitionerRole | Organization | CareTeam | Patient | RelatedPerson) Who is responsible for the observation
... Slices for value[x] SΣC 0..1 Ergebniswert
Slice: Unordered, Open by type:$this
.... valueQuantity Quantity
.... valueCodeableConcept CodeableConcept
.... valueString string
.... valueBoolean boolean
.... valueInteger integer
.... valueRange Range
.... valueRatio Ratio
.... valueSampledData SampledData
.... valueTime time
.... valueDateTime dateTime
.... valuePeriod Period
.... value[x]:valueQuantity ΣC 0..1 Quantity Actual result
... dataAbsentReason C 0..1 CodeableConcept Why the result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
... note 0..* Annotation Comments about the observation
... bodySite 0..1 CodeableConcept Observed body part
Binding: SNOMEDCTBodyStructures (example): Codes describing anatomical locations. May include laterality.
... method 0..1 CodeableConcept How it was done
Binding: ObservationMethods (example): Methods for simple observations.
... specimen S 0..1 Reference(Specimen) Probe
... device 0..1 Reference(Device | DeviceMetric) (Measurement) Device
... referenceRange C 0..* BackboneElement Provides guide for interpretation
Constraints: obs-3
.... id 0..1 string Unique id for inter-element referencing
.... extension 0..* Extension Additional content defined by implementations
.... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
.... low C 0..1 SimpleQuantity Low Range, if relevant
.... high C 0..1 SimpleQuantity High Range, if relevant
.... type 0..1 CodeableConcept Reference range qualifier
Binding: ObservationReferenceRangeMeaningCodes (preferred): Code for the meaning of a reference range.
.... appliesTo 0..* CodeableConcept Reference range population
Binding: ObservationReferenceRangeAppliesToCodes (example): Codes identifying the population the reference range applies to.
.... age 0..1 Range Applicable age range, if relevant
.... text 0..1 string Text based reference range in an observation
... hasMember Σ 0..* Reference(Observation | QuestionnaireResponse | MolecularSequence) Related resource that belongs to the Observation group
... Slices for derivedFrom SΣ 0..* Reference(DocumentReference | ImagingStudy | Media | QuestionnaireResponse | Observation | MolecularSequence) Abgeleitet von
Slice: Unordered, Open by profile:resolve()
.... derivedFrom:variant Σ 0..* Reference(MII PR MolGen Variante) Variant the biomarker is derived from
.... derivedFrom:genotype Σ 0..* Reference(Genotype) Genotype the biomarker is derived from
.... derivedFrom:haplotype Σ 0..* Reference(Haplotype) Haplotype the biomarker is derived from
... Slices for component SΣ 0..* BackboneElement Komponenten
Slice: Unordered, Open by value:code
.... component:All Slices Content/Rules for all slices
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
..... value[x] Σ 0..1 Actual component result
...... valueQuantity Quantity
...... valueCodeableConcept CodeableConcept
...... valueString string
...... valueBoolean boolean
...... valueInteger integer
...... valueRange Range
...... valueRatio Ratio
...... valueSampledData SampledData
...... valueTime time
...... valueDateTime dateTime
...... valuePeriod Period
..... dataAbsentReason C 0..1 CodeableConcept Why the component result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
..... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
..... referenceRange 0..* See referenceRange (Observation) Provides guide for interpretation of component result
.... component:gene-studied SΣ 0..* BackboneElement Untersuchtes Gen
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept 48018-6
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://loinc.org
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: 48018-6
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept The HGNC gene symbol is to be used as display text and the HGNC gene ID used as the code. If no HGNC code issued for this gene yet, NCBI gene IDs SHALL be used.
Binding: HUGO Gene Nomenclature Committee Gene Names (HGNC) (extensible)
..... dataAbsentReason C 0..1 CodeableConcept Why the component result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
..... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
..... referenceRange 0..* See referenceRange (Observation) Provides guide for interpretation of component result
.... component:biomarker-category SΣ 0..* BackboneElement Biomarker-Kategorie
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept cell receptor | antigen | protein | immune stain
Binding: Molecular Biomarker Categories (example)
..... dataAbsentReason C 0..1 CodeableConcept Why the component result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
..... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
..... referenceRange 0..* See referenceRange (Observation) Provides guide for interpretation of component result

doco Documentation for this format

Terminology Bindings

Path Status Usage ValueSet Version Source
Observation.language Base preferred Common Languages 📦4.0.1 FHIR Std.
Observation.status Base required ObservationStatus 📍4.0.1 FHIR Std.
Observation.category Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:labCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:mbCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:geCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.code Base example Molecular Biomarker Codes 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.
Observation.bodySite Base example SNOMED CT Body Structures 📦4.0.1 FHIR Std.
Observation.method Base example Observation Methods 📦4.0.1 FHIR Std.
Observation.referenceRange.​type Base preferred Observation Reference Range Meaning Codes 📦4.0.1 FHIR Std.
Observation.referenceRange.​appliesTo Base example Observation Reference Range Applies To Codes 📦4.0.1 FHIR Std.
Observation.component.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component.​dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.component.​interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​value[x] Base extensible HUGO Gene Nomenclature Committee Gene Names (HGNC) 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component:gene-studied.​dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​value[x] Base example Molecular Biomarker Categories 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component:biomarker-category.​dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.

Constraints

Id Grade Path(s) Description Expression
dom-2 error Observation If the resource is contained in another resource, it SHALL NOT contain nested Resources contained.contained.empty()
dom-3 error Observation If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4 error Observation If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5 error Observation If a resource is contained in another resource, it SHALL NOT have a security label contained.meta.security.empty()
dom-6 best practice Observation A resource should have narrative for robust management text.`div`.exists()
ele-1 error **ALL** elements All FHIR elements must have a @value or children hasValue() or (children().count() > id.count())
ext-1 error **ALL** extensions Must have either extensions or value[x], not both extension.exists() != value.exists()
obs-3 error Observation.referenceRange Must have at least a low or a high or text low.exists() or high.exists() or text.exists()
obs-6 error Observation dataAbsentReason SHALL only be present if Observation.value[x] is not present dataAbsentReason.empty() or value.empty()
obs-7 error Observation If Observation.code is the same as an Observation.component.code then the value element associated with the code SHALL NOT be present value.empty() or component.code.where(coding.intersect(%resource.code.coding).exists()).empty()

Diese Struktur ist abgeleitet von MII_PR_MolGen_MolekularerBiomarker

Summary

Mandatory: 1 element
Must-Support: 3 elements

Slices

This structure defines the following Slices:

  • The element 1 is sliced based on the value of Observation.value[x]

Schlüsselelemente-Ansicht

NameFlagsCard.TypeDescription & Constraints    Filter: Filtersdoco
.. Observation C 0..* MII_PR_MolGen_MolekularerBiomarker Measurements and simple assertions
Constraints: obs-6, obs-7
... implicitRules ?!Σ 0..1 uri A set of rules under which this content was created
... modifierExtension ?! 0..* Extension Extensions that cannot be ignored
... status ?!SΣ 1..1 code Status
Binding: ObservationStatus (required): Codes providing the status of an observation.
.... category:labCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/observation-category
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: laboratory
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
.... category:mbCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
.... category:geCategory 0..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/v2-0074
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: GE
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
... code SΣ 1..1 CodeableConcept Code
Binding: Molecular Biomarker Codes (example)
... subject SΣ 1..1 Reference(Patient | Group) Patient
... encounter SΣ 0..1 Reference(Encounter) Kontakt
... effective[x] SΣ 0..1 Zeitpunkt der Beobachtung
.... effectiveDateTime dateTime
.... effectivePeriod Period
.... effectiveTiming Timing
.... effectiveInstant instant
... issued SΣ 0..1 instant Freigabedatum
... Slices for value[x] SΣC 0..1 Ergebniswert
Slice: Unordered, Open by type:$this
.... valueQuantity Quantity
.... valueCodeableConcept CodeableConcept
.... valueString string
.... valueBoolean boolean
.... valueInteger integer
.... valueRange Range
.... valueRatio Ratio
.... valueSampledData SampledData
.... valueTime time
.... valueDateTime dateTime
.... valuePeriod Period
.... value[x]:valueQuantity ΣC 0..1 Quantity Actual result
... specimen S 0..1 Reference(Specimen) Probe
... Slices for derivedFrom SΣ 0..* Reference(DocumentReference | ImagingStudy | Media | QuestionnaireResponse | Observation | MolecularSequence) Abgeleitet von
Slice: Unordered, Open by profile:resolve()
.... derivedFrom:variant Σ 0..* Reference(MII PR MolGen Variante) Variant the biomarker is derived from
.... derivedFrom:genotype Σ 0..* Reference(Genotype) Genotype the biomarker is derived from
.... derivedFrom:haplotype Σ 0..* Reference(Haplotype) Haplotype the biomarker is derived from
... Slices for component SΣ 0..* BackboneElement Komponenten
Slice: Unordered, Open by value:code
.... component:All Slices Content/Rules for all slices
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
.... component:gene-studied SΣ 0..* BackboneElement Untersuchtes Gen
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept 48018-6
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://loinc.org
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: 48018-6
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept The HGNC gene symbol is to be used as display text and the HGNC gene ID used as the code. If no HGNC code issued for this gene yet, NCBI gene IDs SHALL be used.
Binding: HUGO Gene Nomenclature Committee Gene Names (HGNC) (extensible)
.... component:biomarker-category SΣ 0..* BackboneElement Biomarker-Kategorie
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept cell receptor | antigen | protein | immune stain
Binding: Molecular Biomarker Categories (example)

doco Documentation for this format

Terminology Bindings

Path Status Usage ValueSet Version Source
Observation.status Base required ObservationStatus 📍4.0.1 FHIR Std.
Observation.category Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:labCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:mbCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:geCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.code Base example Molecular Biomarker Codes 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​value[x] Base extensible HUGO Gene Nomenclature Committee Gene Names (HGNC) 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component:biomarker-category.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​value[x] Base example Molecular Biomarker Categories 📦3.0.0 Genomics Reporting Implementation Guide v3.0

Constraints

Id Grade Path(s) Description Expression
dom-2 error Observation If the resource is contained in another resource, it SHALL NOT contain nested Resources contained.contained.empty()
dom-3 error Observation If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4 error Observation If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5 error Observation If a resource is contained in another resource, it SHALL NOT have a security label contained.meta.security.empty()
dom-6 best practice Observation A resource should have narrative for robust management text.`div`.exists()
ele-1 error **ALL** elements All FHIR elements must have a @value or children hasValue() or (children().count() > id.count())
ext-1 error **ALL** extensions Must have either extensions or value[x], not both extension.exists() != value.exists()
obs-6 error Observation dataAbsentReason SHALL only be present if Observation.value[x] is not present dataAbsentReason.empty() or value.empty()
obs-7 error Observation If Observation.code is the same as an Observation.component.code then the value element associated with the code SHALL NOT be present value.empty() or component.code.where(coding.intersect(%resource.code.coding).exists()).empty()

Differential-Ansicht

Diese Struktur ist abgeleitet von MII_PR_MolGen_MolekularerBiomarker

NameFlagsCard.TypeDescription & Constraints    Filter: Filtersdoco
.. Observation 0..* MII_PR_MolGen_MolekularerBiomarker Measurements and simple assertions
... status S 1..1 code Status
... code 1..1 CodeableConcept Code
... subject 1..1 Reference(Patient | Group) Patient
.... value[x]:valueQuantity 0..1 Quantity Actual result
... specimen S 0..1 Reference(Specimen) Probe

doco Documentation for this format

Snapshot-AnsichtView

NameFlagsCard.TypeDescription & Constraints    Filter: Filtersdoco
.. Observation C 0..* MII_PR_MolGen_MolekularerBiomarker Measurements and simple assertions
Constraints: obs-6, obs-7
... id Σ 0..1 id Logical id of this artifact
... meta Σ 0..1 Meta Metadata about the resource
... implicitRules ?!Σ 0..1 uri A set of rules under which this content was created
... language 0..1 code Language of the resource content
Binding: CommonLanguages (preferred): A human language.
Additional BindingsPurpose
AllLanguages Max Binding
... text 0..1 Narrative Text summary of the resource, for human interpretation
This profile does not constrain the narrative in regard to content, language, or traceability to data elements
... contained 0..* Resource Contained, inline Resources
... extension 0..* Extension Additional content defined by implementations
... modifierExtension ?! 0..* Extension Extensions that cannot be ignored
... identifier Σ 0..* Identifier Business Identifier for observation
... basedOn Σ 0..* Reference(CarePlan | DeviceRequest | ImmunizationRecommendation | MedicationRequest | NutritionOrder | ServiceRequest) Fulfills plan, proposal or order
... partOf Σ 0..* Reference(MedicationAdministration | MedicationDispense | MedicationStatement | Procedure | Immunization | ImagingStudy) Part of referenced event
... status ?!SΣ 1..1 code Status
Binding: ObservationStatus (required): Codes providing the status of an observation.
... Slices for category S 2..* CodeableConcept Kategorie
Slice: Unordered, Open by value:coding
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
.... category:labCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
Slice: Unordered, Open by value:url
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/observation-category
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: laboratory
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
..... text Σ 0..1 string Plain text representation of the concept
.... category:mbCategory 1..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
Slice: Unordered, Open by value:url
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
..... text Σ 0..1 string Plain text representation of the concept
.... category:geCategory 0..1 CodeableConcept Classification of type of observation
Binding: ObservationCategoryCodes (preferred): Codes for high level observation categories.
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
Slice: Unordered, Open by value:url
..... coding Σ 1..1 Coding Code defined by a terminology system

Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... system 1..1 uri Identity of the terminology system
Fixed Value: http://terminology.hl7.org/CodeSystem/v2-0074
...... version 0..1 string Version of the system - if relevant
...... code 1..1 code Symbol in syntax defined by the system
Fixed Value: GE
...... display 0..1 string Representation defined by the system
...... userSelected 0..1 boolean If this coding was chosen directly by the user
..... text Σ 0..1 string Plain text representation of the concept
... code SΣ 1..1 CodeableConcept Code
Binding: Molecular Biomarker Codes (example)
... subject SΣ 1..1 Reference(Patient | Group) Patient
... focus Σ 0..* Reference(Resource) What the observation is about, when it is not about the subject of record
... encounter SΣ 0..1 Reference(Encounter) Kontakt
... effective[x] SΣ 0..1 Zeitpunkt der Beobachtung
.... effectiveDateTime dateTime
.... effectivePeriod Period
.... effectiveTiming Timing
.... effectiveInstant instant
... issued SΣ 0..1 instant Freigabedatum
... performer Σ 0..* Reference(Practitioner | PractitionerRole | Organization | CareTeam | Patient | RelatedPerson) Who is responsible for the observation
... Slices for value[x] SΣC 0..1 Ergebniswert
Slice: Unordered, Open by type:$this
.... valueQuantity Quantity
.... valueCodeableConcept CodeableConcept
.... valueString string
.... valueBoolean boolean
.... valueInteger integer
.... valueRange Range
.... valueRatio Ratio
.... valueSampledData SampledData
.... valueTime time
.... valueDateTime dateTime
.... valuePeriod Period
.... value[x]:valueQuantity ΣC 0..1 Quantity Actual result
... dataAbsentReason C 0..1 CodeableConcept Why the result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
... note 0..* Annotation Comments about the observation
... bodySite 0..1 CodeableConcept Observed body part
Binding: SNOMEDCTBodyStructures (example): Codes describing anatomical locations. May include laterality.
... method 0..1 CodeableConcept How it was done
Binding: ObservationMethods (example): Methods for simple observations.
... specimen S 0..1 Reference(Specimen) Probe
... device 0..1 Reference(Device | DeviceMetric) (Measurement) Device
... referenceRange C 0..* BackboneElement Provides guide for interpretation
Constraints: obs-3
.... id 0..1 string Unique id for inter-element referencing
.... extension 0..* Extension Additional content defined by implementations
.... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
.... low C 0..1 SimpleQuantity Low Range, if relevant
.... high C 0..1 SimpleQuantity High Range, if relevant
.... type 0..1 CodeableConcept Reference range qualifier
Binding: ObservationReferenceRangeMeaningCodes (preferred): Code for the meaning of a reference range.
.... appliesTo 0..* CodeableConcept Reference range population
Binding: ObservationReferenceRangeAppliesToCodes (example): Codes identifying the population the reference range applies to.
.... age 0..1 Range Applicable age range, if relevant
.... text 0..1 string Text based reference range in an observation
... hasMember Σ 0..* Reference(Observation | QuestionnaireResponse | MolecularSequence) Related resource that belongs to the Observation group
... Slices for derivedFrom SΣ 0..* Reference(DocumentReference | ImagingStudy | Media | QuestionnaireResponse | Observation | MolecularSequence) Abgeleitet von
Slice: Unordered, Open by profile:resolve()
.... derivedFrom:variant Σ 0..* Reference(MII PR MolGen Variante) Variant the biomarker is derived from
.... derivedFrom:genotype Σ 0..* Reference(Genotype) Genotype the biomarker is derived from
.... derivedFrom:haplotype Σ 0..* Reference(Haplotype) Haplotype the biomarker is derived from
... Slices for component SΣ 0..* BackboneElement Komponenten
Slice: Unordered, Open by value:code
.... component:All Slices Content/Rules for all slices
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
..... value[x] Σ 0..1 Actual component result
...... valueQuantity Quantity
...... valueCodeableConcept CodeableConcept
...... valueString string
...... valueBoolean boolean
...... valueInteger integer
...... valueRange Range
...... valueRatio Ratio
...... valueSampledData SampledData
...... valueTime time
...... valueDateTime dateTime
...... valuePeriod Period
..... dataAbsentReason C 0..1 CodeableConcept Why the component result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
..... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
..... referenceRange 0..* See referenceRange (Observation) Provides guide for interpretation of component result
.... component:gene-studied SΣ 0..* BackboneElement Untersuchtes Gen
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept 48018-6
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://loinc.org
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: 48018-6
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept The HGNC gene symbol is to be used as display text and the HGNC gene ID used as the code. If no HGNC code issued for this gene yet, NCBI gene IDs SHALL be used.
Binding: HUGO Gene Nomenclature Committee Gene Names (HGNC) (extensible)
..... dataAbsentReason C 0..1 CodeableConcept Why the component result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
..... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
..... referenceRange 0..* See referenceRange (Observation) Provides guide for interpretation of component result
.... component:biomarker-category SΣ 0..* BackboneElement Biomarker-Kategorie
..... id 0..1 string Unique id for inter-element referencing
..... extension 0..* Extension Additional content defined by implementations
..... modifierExtension ?!Σ 0..* Extension Extensions that cannot be ignored even if unrecognized
..... code Σ 1..1 CodeableConcept Type of component observation (code / type)
Binding: LOINCCodes (example): Codes identifying names of simple observations.
Required Pattern: At least the following
...... id 0..1 string Unique id for inter-element referencing
...... extension 0..* Extension Additional content defined by implementations
...... coding 1..* Coding Code defined by a terminology system
Fixed Value: (Complex)
....... id 0..1 string Unique id for inter-element referencing
....... extension 0..* Extension Additional content defined by implementations
....... system 1..1 uri Identity of the terminology system
Fixed Value: http://hl7.org/fhir/uv/genomics-reporting/CodeSystem/tbd-codes-cs
....... version 0..1 string Version of the system - if relevant
....... code 1..1 code Symbol in syntax defined by the system
Fixed Value: biomarker-category
....... display 0..1 string Representation defined by the system
....... userSelected 0..1 boolean If this coding was chosen directly by the user
...... text 0..1 string Plain text representation of the concept
..... value[x] Σ 1..1 CodeableConcept cell receptor | antigen | protein | immune stain
Binding: Molecular Biomarker Categories (example)
..... dataAbsentReason C 0..1 CodeableConcept Why the component result is missing
Binding: DataAbsentReason (extensible): Codes specifying why the result (Observation.value[x]) is missing.
..... interpretation 0..* CodeableConcept High, low, normal, etc.
Binding: ObservationInterpretationCodes (extensible): Codes identifying interpretations of observations.
..... referenceRange 0..* See referenceRange (Observation) Provides guide for interpretation of component result

doco Documentation for this format

Terminology Bindings

Path Status Usage ValueSet Version Source
Observation.language Base preferred Common Languages 📦4.0.1 FHIR Std.
Observation.status Base required ObservationStatus 📍4.0.1 FHIR Std.
Observation.category Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:labCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:mbCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.category:geCategory Base preferred Observation Category Codes 📦4.0.1 FHIR Std.
Observation.code Base example Molecular Biomarker Codes 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.
Observation.bodySite Base example SNOMED CT Body Structures 📦4.0.1 FHIR Std.
Observation.method Base example Observation Methods 📦4.0.1 FHIR Std.
Observation.referenceRange.​type Base preferred Observation Reference Range Meaning Codes 📦4.0.1 FHIR Std.
Observation.referenceRange.​appliesTo Base example Observation Reference Range Applies To Codes 📦4.0.1 FHIR Std.
Observation.component.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component.​dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.component.​interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​value[x] Base extensible HUGO Gene Nomenclature Committee Gene Names (HGNC) 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component:gene-studied.​dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.component:gene-studied.​interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​code Base example LOINC Codes 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​value[x] Base example Molecular Biomarker Categories 📦3.0.0 Genomics Reporting Implementation Guide v3.0
Observation.component:biomarker-category.​dataAbsentReason Base extensible DataAbsentReason 📦4.0.1 FHIR Std.
Observation.component:biomarker-category.​interpretation Base extensible Observation Interpretation Codes 📦4.0.1 FHIR Std.

Constraints

Id Grade Path(s) Description Expression
dom-2 error Observation If the resource is contained in another resource, it SHALL NOT contain nested Resources contained.contained.empty()
dom-3 error Observation If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4 error Observation If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5 error Observation If a resource is contained in another resource, it SHALL NOT have a security label contained.meta.security.empty()
dom-6 best practice Observation A resource should have narrative for robust management text.`div`.exists()
ele-1 error **ALL** elements All FHIR elements must have a @value or children hasValue() or (children().count() > id.count())
ext-1 error **ALL** extensions Must have either extensions or value[x], not both extension.exists() != value.exists()
obs-3 error Observation.referenceRange Must have at least a low or a high or text low.exists() or high.exists() or text.exists()
obs-6 error Observation dataAbsentReason SHALL only be present if Observation.value[x] is not present dataAbsentReason.empty() or value.empty()
obs-7 error Observation If Observation.code is the same as an Observation.component.code then the value element associated with the code SHALL NOT be present value.empty() or component.code.where(coding.intersect(%resource.code.coding).exists()).empty()

Diese Struktur ist abgeleitet von MII_PR_MolGen_MolekularerBiomarker

Summary

Mandatory: 1 element
Must-Support: 3 elements

Slices

This structure defines the following Slices:

  • The element 1 is sliced based on the value of Observation.value[x]



Weitere Repräsentationen des Profils: CSV, Excel, Schematron
